The Ultimate Guide to Socket Fitting Series: 135° HDPE Elbow
Introduction
HDPE (High-Density Polyethylene) 135° elbows are essential components in modern piping systems, providing a reliable and durable solution for creating angled connections. This comprehensive guide will cover the specifications, applications, and benefits of HDPE 135° elbows, helping you understand why they are a preferred choice for various industries.
What is an HDPE Socket Fitting 135° Elbow?
An HDPE socket fitting 135° elbow is a specialized fitting designed to create a 135-degree turn in HDPE piping systems. This fitting allows for smooth fluid flow and is particularly useful in applications where space constraints require a more compact design compared to a 90-degree elbow. The socket fitting design allows for easy installation and a secure connection.
Key Specifications
Material
Raw Material: High-Density Polyethylene (HDPE), typically PE100 or PE4710.
Color: Black or blue, with other colors available upon request.
Size Range
Diameter Range: DN20 to DN800mm (1/2 inch to 32 inches).
Common Sizes: 2 inches (50 mm), 4 inches (100 mm), 6 inches (150 mm), 8 inches (200 mm) and above.
Pressure Rating
Pressure Classes: SDR11-PN16, SDR17-PN10.
Pressure Ratings: PN16 for water and PN10 for gas.
Manufacturing Process
Process: Injection molded in one piece for precision and strength.
Standards: Conforms to ISO4427-3, EN12201-3, AS/NZS 4129, EN1555, EN ISO15494.
Applications
HDPE socket fitting 135° elbows are versatile and used in a variety of industries due to their durability and resistance to corrosion. They are ideal for:
Municipal Water Supply: Ensuring reliable water distribution in urban areas.
Gas Distribution Networks: Preventing leaks in gas lines.
Agricultural Irrigation: Connecting main and branch pipes in irrigation systems.
Industrial Fluid Handling: Handling various industrial fluids in chemical processing plants.
Mining and Dredging Projects: Managing fluid flow in harsh environments.
Benefits of HDPE Socket Fitting 135° Elbows
High-Strength Connection
The socket fitting process creates a joint that is as strong as the pipe itself, ensuring a durable and leak-free connection.
Corrosion Resistance
HDPE material is highly resistant to chemical corrosion, making it suitable for handling corrosive media.
Temperature Resistance
HDPE elbows maintain their physical properties across a wide temperature range, making them suitable for various environmental conditions.
Easy Installation
The socket fitting process is straightforward and does not require additional materials or fittings, simplifying the installation process.
Cost-Effective
HDPE socket fitting 135° elbows offer an excellent price-to-performance ratio, making them a cost-effective solution for both small and large-scale projects.
Choosing the Right HDPE Socket Fitting 135° Elbow
When selecting an HDPE socket fitting 135° elbow, consider the following factors:
Size and Pressure Requirements: Ensure the elbow matches the diameter and pressure requirements of your piping system.
Connection Type: Choose an elbow that is suitable for socket fitting.
Standards and Certifications: Look for elbows that meet relevant industry standards to ensure quality and reliability.
Manufacturer's Reputation: Select a reputable manufacturer to ensure high-quality products and reliable technical support.
Conclusion
HDPE socket fitting 135° elbows are essential for creating reliable and durable connections in HDPE piping systems. Their strength, corrosion resistance, and ease of installation make them a preferred choice for various applications. By choosing the right HDPE socket fitting 135° elbow, you can ensure the long-term success and efficiency of your piping system.
For more information or to purchase HDPE socket fitting 135° elbows, contact a reputable supplier who can provide detailed specifications and support for your specific needs.
